C-type Integrated Multi-element Meteorological Transmitter

C-type Integrated Multi-element Meteorological Transmitter

The C - type integrated multi - element meteorological transmitter is a highly advanced device. It is designed to accurately measure multiple meteorological parameters simultaneously. With its integrated structure, it occupies less space and is easy to install. This transmitter can precisely monitor temperature, humidity, wind speed, and other elements. It plays a crucial role in weather forecasting, environmental monitoring, and various meteorological - related fields, providing reliable data for accurate analysis.
  • Product Model :

    C-type
  • Power Supply Mode :

    10-30 VDC
  • Interface :

    RS485
  • Protocol :

    ModBus-RTU
The C - type integrated multi - element meteorological transmitter is a state - of - the - art device. It can precisely measure various meteorological elements such as temperature, humidity, wind speed, and wind direction. Its integrated design makes it compact and easy to install, reducing the need for complex setups.
This transmitter is widely used in many fields. In weather forecasting, it provides accurate data for accurate predictions. In environmental monitoring, it helps assess air quality and climate changes. Additionally, it plays a significant role in agriculture, aviation, and maritime industries, ensuring smooth operations and safety.
Technical Parameter
DC Power Supply (default) 10-30VDC
Maximum Power Consumption RS485 output 0.8W
Range Wind Speed 0~70m/s
Wind Direction 8 indication directions
Humidity 0%RH~99%RH
Temperature -40℃~+80℃
Atmospheric Pressure 0-120kPa
Noise 30dB~120dB
PM10 PM2.5 0-1000μg/m³
CO2 0-5000ppm
Accuracy Wind Speed ± (0.2+0.03V) m/s V represents wind speed (60% RH, 25 ℃)
Wind Direction -
Humidity ±3%RH(60%RH,25℃)
Temperature ±0.5℃(25℃)
Atmospheric Pressure ±0.15kPa@25℃ 101kPa
Noise ± 0.5dB (at reference pitch, 94dB@1kHz )
PM10 PM2.5

Particle counting efficiency:

50% @ 0.3 μ m, 98% @>=0.5 μ m.

PM2.5 accuracy: ± 3% FS (@ 0~100 μ g/m3, 25 ℃, 50% RH)

CO2 ±(50ppm+ 3%F·S) (25℃)
Output Signal RS485 RS485 (Standard ModBus Communication Protocol)
